ZR10001 1000W Monoblock Class-D Amplifier

Featuring massive power, the ZR10001 uses its high grade connection terminal to ensure a clean crisp power delivery to all your components.

the ZR10001, a formidable 1000W Monoblock Class-D Amplifier that effortlessly blends power, sophistication, and versatility. Boasting a design that exudes brilliance and functionality, this amplifier is engineered to cater to a diverse range of installations, setting new standards in sonic performance.

The ZR10001 is a pinnacle within the acclaimed ZR series, embodying the core DNA of precision, control, and unbridled power. Crafted to evoke joy and satisfaction, these amplifiers are a fusion of cutting-edge technology and enduring reliability, ensuring an audio experience that transcends the ordinary.

At its heart lies the latest generation Class-D chipset, a testament to relentless innovation and commitment to longevity. These amplifiers have been designed to endure extended usage, promising not just performance but the ability to sustain an atmosphere.

The power of the ZR10001, an astounding 1000W at 1 ohm, 670W at 2 ohms, and 385W at 4 ohms. This remarkable adaptability across varying impedance levels ensures seamless integration into a wide spectrum of audio setups, from power-hungry systems to more nuanced, controlled environments, allowing users to sculpt their audio experience to perfection.

Compact yet commanding, this amplifier boasts dimensions of 253.66 x 160 x 48.3mm, a testament to its ability to seamlessly blend into diverse installations without compromising on performance. Its features amplify its appeal further: a 24dB Low Pass Filter, adjustable Bass Boost ranging from 0 to 18dB, Phase Control spanning 0 to 180 degrees, and a Subsonic Filter covering frequencies from 10Hz to 55Hz.

ZR10001 Product Specifications:

• Class: D
• Channels: 1
• Frequency Response: 20Hz – 400Hz
• RMS Power Rating (1Ω): 1 x 1000W
• RMS Power Rating (2Ω): 1 x 670W
• RMS Power Rating (4Ω): 1 x 385 W
• Signal to Noise Ratio (SNR) (Full Power): -80dB
• Total Harmonic Distortion (THD): <1%
• Low-Pass Filter: 50Hz – 250Hz (24dB/Oct)
• Subsonic: 10Hz – 55Hz (24dB/Oct)
• Bass Boost @ 45Hz: 0 – +18dB
• Input Sensitivity: 0.25V – 10V
• Fuses: 3 x 35A
• Remote Controller: Yes (Included)
• High-Level Input Via RCA: Yes
• Auto Turn-On: Yes
• Phase Control: 0° – 180°
• Operatig Voltage: 9V – 16V
• Idle Current: 0.9A
• Current Draw (Max): 97A
• Total Efficiency (4Ω): 86%
• Power Terminal: 20mm²
• Speaker Terminal: 4mm²
